The 20-2500kVA SDEC Diesel Generator leverages Shanghai Diesel Engine Co.’s (SDEC) 70-year legacy of industrial engine innovation to deliver scalable, high-performance power for demanding industrial environments. Powered by SDEC’s technologically advanced SC4H (20-100kVA) and SC33W (1000-2500kVA) engines—designed with reinforced components for heavy-duty operation—it achieves ≤82dB(A) noise levels (at 7m) and exceptional 202g/kWh fuel efficiency (measured on 500kVA model at full load). Its modular design allows easy capacity expansion, making it ideal for growing industrial facilities that require flexible power scaling.
High Torque Output: Delivers 4,800 N·m torque at 1,500 rpm (on SC13E550D2 model), providing robust power to drive heavy machinery such as crushers, conveyor belts, and industrial pumps—even during sudden load spikes .
Advanced Cooling System: Offers dual cooling options (keel-cooled for water-rich environments or plate heat exchanger for dry regions), eliminating the need for freshwater cooling systems and reducing maintenance costs by 30% compared to traditional cooling setups .
Plateau Adaptability: Specifically optimized for high-altitude operations (up to 5,000m) with modified turbocharging systems and fuel injection calibration, ensuring power drop remains <3%—critical for mining, oil & gas, and construction applications in mountainous areas .
Remote Monitoring: SDEC’s proprietary iPM (Intelligent Power Management) system provides real-time diagnostics, performance analytics, and predictive maintenance alerts via cloud-based platform, reducing unplanned downtime by 30% through early fault detection .
Certifications: ISO 9001:2018 (quality management) and CE-certified, with optional UL and CSA approvals for North American markets, ensuring compliance with global industrial safety and performance standards .
Manufacturing Facilities: Powers 24/7 assembly lines, robotic welding systems, and precision machining centers in automotive, electronics, and aerospace factories, with redundant power configurations (parallel operation of 2-4 units) to prevent production halts.
Mining Operations: Supports underground conveyor systems, ventilation fans, and ore processing equipment, with explosion-proof variants (ATEX-certified) available for hazardous zones containing flammable gases or dust.
Power Plants: Serves as baseload power for remote microgrids and integrates with combined heat and power (CHP) systems, capturing waste heat for industrial processes or district heating to achieve overall energy efficiency of 85% .
Q: What voltage configurations are available?
A: Standard configurations include 400/230V three-phase (50Hz) for European/Asian markets and 480V (60Hz) for North America. Customizable options up to 11kV are available for large industrial grids, with step-up transformers integrated for high-voltage applications .
Q: What is the maintenance interval?
A: Routine maintenance (oil and filter changes, coolant checks) is recommended every 500 hours of operation. Major overhauls (including cylinder head inspection and fuel injector servicing) are required every 10,000 hours, with extended intervals possible under light load conditions .
